VCV Rack - VCA , Linear Inputs & Exponential Inputs
What Will I Learn?
- You will learn how to use a Voltage Controlled Amplifier.
- You will learn about an exponential input.
- You will learn about a linear input.
Requirements
To complete this tutorial learners will need to have the following:
- The software application VCV Rack installed
- Access to the Internet
- An account created on www.vcvrack.com
- Fundamental and Autodafe plugins installed
Difficulty
This tutorial is at an Beginner level.
Description
Learn how to use a Voltage Controlled Amplifier
Fundamental module pack comes with a VCA (Voltage Controlled Amplifier). VCAs are very useful and they will find their way into many of your sound setups.
The VCA is used to control you sound level. It can, obviously amplify the sound and decrease the sound.
VCA has two amplifiers in one module. Both of these are separate. In your setup can have as many VCAs as you need.
- You will learn about Linear Inputs
VCA is 'voltage controlled' so it can be manipulated by a separate module. There are two inputs for this control on both the upper and lower VCAs. We are given one Linear input and one Exponential input.
When you connect a control voltage from a separate module to the Linear input of the VCA the changes in voltage from the external module will be applied to the amplitude of the signal based on a linear equations. In other words, as the volume increases it will do so in a linear fashion.
- You will learn about Exponential inputs
When Control Voltage is connected to the Exponential input the voltage is processed based on an exponential equation. This means that an increase in volume will be very slow to increase at the beginning of the cycle and increase exponentially near the upper volume levels.
Image Source
VCV Rack is an open source application, which means that it is free for everyone to use. Please consider going to the developers' website and show your support for the project - http://www.vcvrack.com
I hope you enjoy this tutorial. If you have any specific questions for me feel free to leave it in the comments of this post and I will do my best to get back to you with an answer.
Cheers,
@buckydurddle
