Antonov AN-22A Development for FlightGear

Introduction

FlightGear (http://www.flightgear.org) is an open source flight simulator that is even used in flight schools to train basic maneuvers, radio communication and navigation tasks. It is available for windows, mac and linux.

In this article I want to introduce my development of Antonov AN-22A.

Characteristics

• Wikipedia: https://en.wikipedia.org/wiki/Antonov_An-22
• Wingspan 64.40 m (211 ft 4 in)
• Length 57.90 m (189 ft 11 1/2 in)
• Height 12.53 m (41 ft 1 1/2 in)
• Empty weight 114000 kg (251325 lb)
• Engines 4 x Kuznetsov NK-12MA turboprops driving contra-rotating propellers (15000 shp each)
• Payload 80,000 kg (176,350 lb)
• Maximum speed 740 km/h (399 knots, 460 mph)
• Range: 5,000 km (2,700 nm, 3,100 mi) with maximum payload,
• 10,950 km (5,905 nm, 6,800 mi) with maximum fuel and 45,000 kg (99,200 lb) payload

Development steps

• On 7th January 2015 my first commit was made, since then 140 more commits are done.
• I took this model (an-22) from the official repository and improved it step by step in my own hangar and with a new model name AN-22A.
• FDM (Flight Dynamic Model) work to get realistic behavior
• Full Instrumentation in the cockpit with 180 instruments, lamps and switches
• Lots of Animations like paratroopers, tanks transport, ground effects, ambient lightning, doors, smoke for reverse and normal thrust, runway effects
• all Multiplayer compatible
• Autopilot programming
• Nasal programming for engine start up and lots of systems and instruments
• Various video productions with flights uploaded on Youtube and documented on Steemit.
• Some updates made now for fitting the new rules for contributions.

Link to the repository

https://github.com/HerbyW/AN-22A

Proof of work

In my profile on Utopian.io, the github repo AN-22A is listed in my project
page, which is show in the screenshot as follows:

The login page on github.com is shown in the following screenshot:

---
