Lighting For Everyone The STEEMIT Way

The Opensource JOULESTEEM Circuit – Post #90

A Much More Efficient Circuit

The circuit as per the last post had improved a lot with the addition of a diode, see circuit:

For more info, the last post is here:

https://steemit.com/offgrid/@lightingmacsteem/4gdyhb-lighting-for-everyone-the-steemit-way

This post is also to announce the availability of the book that I published at Amazon here:

KINDLE link: https://www.amazon.com/dp/B07HR5G4PB

PAPERBACK link: https://www.amazon.com/dp/1724114859

Please support this initiative as I embark on exposing this type of alternative energy for the benefit of everyone. Those who are willing to support can donate thru my bitcoin wallet here:

“1Bcdfnvr1cQowMBPwnUx9UDN78mBCS6yzT”

A Brief Description On How The Circuit Operates

To describe this latest circuit, the diodes enable the big CAP to accumulate much higher voltages during transistor off times because it is now “blocked” from going into the source battery as blocked by the diode.

If we try to analyze, if the CAP can save much more voltage, it can only mean that it will only drain itself towards the charge battery and the circuit during the transistor on times, thereby prolonging the time it can drain its charge.

The more time the CAP will be discharged, the lesser drain from the source battery.

The CAP is clearly aiding the source battery in this arrangement.

Try it yourself and replicate.

“Power Unused Is Always A Waste……...”
