Electricity: aspects and concepts (in terms of refrigeration and air-conditioning.)

in #stemng6 years ago

ELECTRICITY

image source

INTRODUCTION

Electricity can be defined as the current that flows in amperes. The electricity supply to most home is 220-240 volts(where ohms law come in operation.) As a service technician, you should understand the fundamental of electricity.

Most lighten appliances uses 120v(it will still pickup) but refrigeration and air-conditioning system uses 240volts.

The presence of an electric charge, which can be either positive or negative, produces an electric field. The movement of electric charges is an electric current and produces a magnetic field. source

In refrigeration and air condition, types of electricity used are as follows;
1)Static electricity.
2)Current electricity.


1)Static electricity; Is defined as electricity at rest
2)Current electricity; Is the electricity flowing through a conductor(wires)

image source

Types of electric power supplies.
1)Direct current power supply.
2)Alternating power supply.
3)Single phase alternating power supply.
4)Three phase alternating power supply.

Effect of electricity.
1)Chemical effect.
2)Magnetic effect.
3)Physiological effect.(effect on body)
4)Heating effect

CONDUCTORS AND INSULATORS.

image source

Conductors

Conductor are bodies or materials that will readily permit easy flow of electricity through them. A conductor must always be properly insulated in order to prevent electricity when exposed. The type of insulation used for conductor must have highest resistance, so as to keep the flow of electricity within the conductor.

All metals and alloys are good conductors of electricity, but out of all the metals, silver is regarded as the best conductor of electricity, the reason is because silver offers the best resistance to the flow of electricity as compared to any metal. Conductor is commonly used by the electricity and other technicians, when referring to cables which convey electric current from one point to another.

image source

NOTE:
I)Earth is also a good conductor of electricity, especially when its wet(I.e during the rainy season.)
ii)Power companies make use of aluminium for their transmission lines because of its light in weight, which allows ions spans between towers and poles.


Insulators.

image source

Insulators are bodies that do not allow the flow of electricity through them. In other words, it is the opposite if conductor. Insulation must be flexible, and tough in order to withstand bending and handling. It must be water proof and be able to withstand heat.

The following list of bodies are the efficient insulators in common use; slate oil(used in transformers) porcrain, shellar, dry leather, ebonite, dry paper, mila, wool silk, amber, sealing wax.


ELECTRICAL MEASURING INSTRUMENT AND THEIR USES.

1)Ammeter

image source

This is the instrument used for measuring the strength of current in amperes. It is usually connected in series into a circuit to measure the current flowing through it.

2)Ohmeter:

image source

This single purpose instrument with its wide range and multiple seals, providing fine accuracy while checking resistance measurement over a number of product found in the appliance industry. It can be used to check the resistance of an element as well as resistance of winding of compressor.

3)Wattmeter: This instrument is useful in determining the wattage which an electrical power device consumes.

4)Voltmeter

image source

This special test instrument has been designed and made available for field service men. Making home repair calls on major appliances such as refrigerators, freezer. Etc. Its a dual purpose instrument that permits the checking of both voltage and resistance measurement.

5)Voltwatt meter: This instrument is used to read volts and watts, simultaneously for amperage reading. It also shows faulty power line wiring.

6)Potential meter: Is one of the most useful instrument for the accurate measurement of potential difference, current and resistance.

7)Dynamometer: Is suitable for use with both direct current and alternating current as voltmeter.

Thanks for reading... @vickyrich cares...one love!!!
