IPS vs TN: Right & Wrong Ways To Use Or View; How To Vastly Reduce AHVA/IPS/PLS Glow & Increase The Perceived Black Depth

in monitors •  last year

There is a right and wrong way to use or view each type of LCD panel due to their differently limiting viewing angles. The most important step to optimally viewing each LCD panel type is figuring out the right height for each. Second is the viewing distance which varies per panel type, and between the same types of panels depending on their quality.

Make sure to click on the images to enlarge them and inspect them closely on an AHVA/IPS/PLS panel, CRT, Plasma or OLED which are all free from horizontal and vertical gamma shift unlike TN (vertical) and VA panels (horizontal).

BenQ Zowie RL2460 vs Viewsonic XG2703-GS Lights Onjpg.jpg

In this post the % Brightness refers to the amount from 1-100 in the monitors menu, and the cdm/2 value is the total brightness of white measured with a Spectracal C6 HDR2000 Colorimeter. Photos taken with a Nikon D5200 Camera. The ceiling light used in photos with the lights on is a single 2600 lumen (brightness) Daylight or 6500k (color temperature) Philips CFL light:

Philips 2600 Lumen Daylight or 6500k CFL Light 42w.jpg

AHVA/IPS/PLS panels can not be viewed from above or while being looked down upon without suffering from obvious contrast loss or white glow or vibrancy loss. Despite this AHVA/IPS/PLS panels still have the widest viewing angles, as well as the most accurate, even and vibrant colors.

The top of AHVA/IPS/PLS panels need to line up or be higher than the viewers eyes to eliminate glow. The top left image shows the correct way to view an AHVA/IPS/PLS panel. and is also ideal for keeping proper posture and not hunching:


TN panels have the most restrictive viewing angles both horizontally and vertically, but they do fair better when looked down upon or viewed from above than AHVA/IPS/PLS panels. TN panels can not be viewed while leaning back or from below without darkening significantly which makes them unusable while leaning back, reclining, or placed higher than the viewers eyes. Even slight vertical changes result in obvious darkening:

BenQ Zowie RL2460 Lights Off 1.jpg

Left: TN Panel at 90 degrees versus Right: TN Panel Titled Down Slightly 54% Brightness=140cdm/2

BenQ Zowie RL2460 Lights on Raise vs Right.jpg

Left: TN Panel Raised & Viewed Incorrectly with 54% Brightness=140cdm/2

Right: TN Panel Viewed Correctly=Lowered & Titled Down with 54% Brightness=140cdm/2

TN panels colors are also uneven from top to bottom due to vertical gamma shift. TN panel color is too dark in the top quarter and washed out in the bottom half. TN panels must be viewed like this to get the best image quality out of them:

TN View.gif

Many people who upgrade from TN panels place their AHVA/IPS/PLS panel at the same height and distance. A high amount of AHVA/IPS/PLS horror stories about glow and light bleed are the result of improper use such as keeping the brightness maxed while looking down at, or viewing the AHVA/IPS/PLS panel from above.

VA panels (A-MVA, S-PVA, ect) have the second most restrictive horizontal viewing angles, but suffer from far less contrast loss and glow than AHVA/IPS/PLS panels when looked down upon or viewed from above.


The Order_ 1886_20151110001835.png

Above is the source image, a screenshot I took from The Order 1886 on the Playstation 4.

BenQ Right vs Viewsonig Wrong 100B.jpg

Left: BenQ Zowie RL2460 Viewed Properly 54% Menu Brightness=140cdm/2

Right: Viewsonic XG2703-GS Viewed Incorrectly (lowered or viewed from above) @100% Brightness=370cdm/2

The BenQ looks far less washed out and is free from obvious glow unlike the Viewsonic in this dark scene.


Viewsonic XG2703-GS 100B lowered vs 100B Raised.jpg

Left: Viewsonic XG2703-GS Viewed Incorrectly (lowered or viewed from above) @100% Brightness=370cdm/2

Right: Viewsonic XG2703-GS Viewed Correctly (Raised) @100% Brightness=370cdm/2

Raising the monitor vastly decreases the white glow across the bottom, but the scene still looks washed out since the brightness is maxed. Very bright room lighting would negate this, but many people use their displays in the dark with the brightness cranked and complain about their display looking dull or washed out.


Viewsonic XG2703-GS 100 Brightness Lowered vs 33 Brightness Raised.jpg

Left: Viewsonic XG2703-GS Viewed Incorrectly (lowered or viewed from above) @100% Brightness=370cdm/2

Right: Viewsonic XG2703-GS Viewed Correctly (Raised) @33% Brightness=140cdm/2

Raising the monitor and lowering the brightness to 140cdm/2 results in vastly reduced glow versus the monitor when lowered or viewed from above or while looking down at it like one must when viewing a TN panel. The lowered brightness also results in an image far closer to the source, though 140cdm/2 display brightness is still too bright for light-less room use.


Viewsonic XG2703-GS Lights Off 33 Brightness Lowered vs Raised.jpg

Left: Viewsonic XG2703-GS Viewed Incorrectly (lowered or viewed from above) @33% Brightness=140cdm/2

Right: Viewsonic XG2703-GS Viewed Correctly (Raised) @33% Brightness=140cdm/2

Notice the reduced glow. The glow reduction is not nearly as obvious as with the 100% brightness comparisons, but it makes a very noticeable difference in real life.
