NODE- Intelligent technology for wireless energy

in #hardware7 years ago (edited)


Node are on the final stage of testing of prototype devices. And there is two fundamentally different schemes are being explored and improved upon by Node scientists:

In an induction coil or an electric transformer, which have a metal or air core, the energy is transferred by a simple electromagnetic connection called magnetic induction. Using this method, the transmission and reception of energy became feasible at a considerable distance, but to obtain a significant voltage in this way it was necessary to arrange two coils very close to each other.
A magnetic/capacitive resonant coupling is used, where both inductors are tuned to a mutual frequency, so that a considerable amount of energy can be transmitted over a considerable distance.
The essence of the promising technology from Node is the imposition of several electromagnetic waves in the form of impulses of different duration and frequency to each other, after which these waves pass through a special ferro-electric material and an electromagnetic lens from the structured meta-material.



This one is for EON !


You can know more about the Node Project here in the whitepaper.

https://drive.google.com/viewerng/viewer?url=https://nodepower.io/whitepaper.pdf

Do check their Website as well.

https://nodepower.io/

Proof of Authorisation-

https://bitcointalk.org/index.php?action=profile;u=1198447
